Custom Webhooks

This guide shows how to enable Custom Webhooks, create endpoint subscriptions, validate deliveries, and monitor failures from the Open Saasframe admin UI.

Prerequisites​

  • A publicly reachable HTTPS endpoint that can receive POST requests.
  • The integrations.manage feature if you need to enable or disable the integration.
  • The webhooks.view feature to inspect endpoints and deliveries.
  • The webhooks.manage, webhooks.secrets, and webhooks.test features if you need to create, edit, rotate secrets, or send test deliveries.

Step 1 — Enable the integration and review shared settings​

Go to External Systems → Integrations and open Custom Webhooks.

Custom Webhooks integration settings

Use this screen for the integration-wide controls:

  • The State toggle enables or blocks outbound deliveries, retries, test sends, and inbound webhook receives.
  • The Settings tab links to the webhook list and lets you create a new endpoint quickly.
  • Failed delivery notifications can notify admin users when an endpoint exhausts all retry attempts.
  • The Configured webhooks section gives you shortcuts into existing endpoint detail pages.
tip

Use the integration toggle only when you want to pause the whole webhook subsystem. To stop a single destination, deactivate that specific webhook on its own detail page instead.

Step 2 — Create an endpoint​

Open External Systems → Webhooks and click Create Webhook.

Webhook list

In the create form:

  • Enter a clear Name so operators can identify the consumer quickly.
  • Set the Endpoint URL to your receiving service.
  • Select exact events or wildcard patterns in Subscribed Events.
  • Keep the default retry and timeout values unless your receiver is known to be slow.
  • Add Custom Headers only for static metadata such as environment or source identifiers.

Outbound URL safety​

Open Saasframe rejects webhook URLs that point at localhost, private networks, reserved IP ranges, or internal hostnames. This protects the delivery worker from sending server-side requests to services that only the Open Saasframe host can reach.

For local development or CI, set SF_WEBHOOKS_ALLOW_PRIVATE_URLS=1 to allow endpoints such as http://localhost:3000/webhooks. Keep this disabled in production. Use a public HTTPS endpoint or a temporary public tunnel when testing a production-like environment.

Step 3 — Store the signing secret immediately​

After creating a webhook, Open Saasframe reveals the signing secret only once. The same one-time reveal appears again after a secret rotation.

Webhook secret reveal

Important rules:

  • Copy the whsec_... value into your receiving service before closing the panel.
  • Later reads only show a masked value.
  • If you lose the secret, rotate it and copy the new one from the reveal panel.
  • Your consumer should verify webhook-id, webhook-timestamp, and webhook-signature on every request.

Step 4 — Test the endpoint and inspect delivery details​

Open the webhook detail page and use Send Test before enabling broad event patterns in production.

Webhook detail page

The detail page is the main operator view for one endpoint. It shows:

  • Endpoint URL and subscribed events
  • Retry and auto-disable settings
  • Masked signing secret with an inline Rotate Secret action
  • Last delivery timestamp and consecutive failure count
  • A per-endpoint Delivery Log with request and response details

Use this page when:

  • a single consumer is failing
  • you need to resend a specific delivery
  • you want to confirm the exact payload and response returned by that consumer

Step 5 — Monitor all deliveries from the integration logs tab​

The integration detail page also provides an aggregated delivery view across every configured webhook.

Aggregated webhook delivery log

Use the Logs tab when you want to:

  • review delivery attempts across all webhook destinations in one place
  • filter by delivery status
  • identify which webhook is failing without opening each endpoint manually
  • jump from an aggregated log row to the corresponding webhook detail page

Event patterns​

Custom Webhooks support exact event names and wildcards:

PatternMatches
catalog.product.deletedOnly that event
customers.*All customer events
*All platform events

Prefer exact events when possible. Use broad wildcards only when your consumer is designed to handle a wider event surface.

Troubleshooting​

ProblemWhat to check
No deliveries appearConfirm the integration is enabled and the webhook itself is active. Then verify the event pattern matches a real emitted event name.
Test delivery stays pending or failsOpen the webhook detail page and inspect the delivery log for the HTTP status, response body, and retry state.
Signature verification fails in the consumerMake sure you copied the latest whsec_... value and verify the three Standard Webhooks headers exactly as sent.
You closed the secret reveal panelRotate the secret and copy the new value immediately.
You want alerts when retries are exhaustedTurn on Failed delivery notifications in the integration Settings tab.
