Scheduled Jobs

The Scheduler module allows you to automate recurring tasks by creating scheduled jobs that run at specific times or intervals. You can schedule jobs to execute commands or enqueue tasks to worker queues.

Overview​

The scheduler provides:

  • Cron-based scheduling - Use standard cron expressions for complex timing patterns
  • Interval scheduling - Use simple interval formats like "15m", "2h", or "1d"
  • Multi-tenant isolation - Schedule jobs at system, organization, or tenant scope
  • Timezone support - Run jobs in any timezone
  • Command or queue execution - Target registered commands or worker queues
  • Execution history - Track job runs and troubleshoot failures (in async mode)
  • Manual triggers - Run scheduled jobs on-demand

Accessing Scheduled Jobs​

Navigate to Configuration → Scheduled Jobs in the admin panel.

Scheduled Jobs List

The list shows all configured schedules with:

  • Name - Human-readable job name
  • Type - Cron or Interval
  • Schedule - The cron expression or interval value
  • Target - Whether it executes a Command or Queue job
  • Next Run - When the job will execute next
  • Active - Whether the schedule is enabled
  • Source - Whether created by a user or module

Creating a Schedule​

Click New Schedule to create a new scheduled job.

Create Schedule Form

Basic Information​

  • Name (required) - A descriptive name for the schedule
  • Description (optional) - Additional details about what the job does
  • Scope (required) - Choose the isolation level:
    • System - Runs globally, not tied to any tenant/organization
    • Organization - Runs for a specific organization
    • Tenant - Runs for a specific tenant (default)

Schedule Configuration​

Filled Schedule Form

  • Schedule Type (required) - Choose how to define the schedule:

    • Cron Expression - Use standard 5-field cron syntax
    • Simple Interval - Use interval format (e.g., "15m", "2h", "1d")

  • Schedule Value (required) - The actual schedule:

    • Cron examples:
      • 0 0 * * * - Every day at midnight
      • 0 */6 * * * - Every 6 hours
      • */15 * * * * - Every 15 minutes
      • 0 9 * * 1-5 - Weekdays at 9 AM
    • Interval examples:
      • 30s - Every 30 seconds
      • 15m - Every 15 minutes
      • 2h - Every 2 hours
      • 1d - Every day

  • Timezone (required) - The timezone for schedule execution (default: UTC)

Target Configuration​

  • Target Type (required) - What to execute:

    • Queue - Add a job to a worker queue
    • Command - Execute a registered command

  • Target Queue (for queue type) - The queue name to enqueue to

  • Target Command (for command type) - Select from registered commands

  • Job Arguments (JSON) (optional) - JSON payload passed to the target

    • Must be valid JSON format
    • Example: {"message": "Hello", "value": 42}

Enable/Disable​

Toggle the Enabled switch to activate or deactivate the schedule without deleting it.

Schedule Actions​

From the list view, each schedule has an actions menu:

  • View - See schedule details and execution history
  • Edit - Modify the schedule configuration
  • Run Now - Manually trigger the schedule (requires async mode)
  • Delete - Remove the schedule (soft delete, can be undone)

Execution Strategies​

The scheduler supports two execution strategies:

Local Strategy (Development)​

Environment: QUEUE_STRATEGY=local (default)

  • Polls the database every 30 seconds for due schedules
  • Prevents duplicate execution within the process only — run exactly one scheduler process, or a second one will execute the same due schedule
  • No Redis required
  • Best for development and single-instance deployments

Start the scheduler:

yarn saasframe scheduler start

Keep this process running in a terminal.

Async Strategy (Production)​

Environment: QUEUE_STRATEGY=async

  • Uses BullMQ repeatable jobs for precise timing
  • Requires Redis
  • Supports distributed multi-instance deployments
  • Provides execution history and job details

Setup:

  1. Sync schedules with BullMQ (one-time):
yarn saasframe scheduler start
  1. Start workers in separate processes:
yarn saasframe worker:start

CLI Commands​

The scheduler module provides several CLI commands:

# List all schedules
yarn saasframe scheduler list [--tenant <id>] [--scope <type>] [--enabled <true|false>]

# Show scheduler status
yarn saasframe scheduler status

# Manually run a schedule
yarn saasframe scheduler run <schedule-id>

# Start scheduler engine
yarn saasframe scheduler start

Common Use Cases​

Daily Reports​

Schedule a report generation job to run every morning:

  • Schedule Type: Cron
  • Schedule Value: 0 6 * * * (6 AM daily)
  • Target: Queue or Command for report generation

Data Synchronization​

Sync data with external services every 15 minutes:

  • Schedule Type: Interval
  • Schedule Value: 15m
  • Target: Command for data sync

Cleanup Tasks​

Remove old records weekly:

  • Schedule Type: Cron
  • Schedule Value: 0 2 * * 0 (2 AM every Sunday)
  • Target: Command for cleanup

Currency Rate Updates​

Fetch exchange rates every 6 hours:

  • Schedule Type: Cron
  • Schedule Value: 0 */6 * * *
  • Target: Queue job for rate fetching

Access Control​

The scheduler module uses these features for access control:

  • scheduler.jobs.view - View scheduled jobs
  • scheduler.jobs.manage - Create, edit, and delete schedules
  • scheduler.jobs.trigger - Manually trigger schedule execution

Users need the appropriate features assigned to their role to access scheduler functionality.

Best Practices​

  1. Use descriptive names - Make it clear what each schedule does
  2. Set appropriate scopes - Use System scope only when truly global
  3. Test with intervals first - Use simple intervals during development, switch to cron for production
  4. Monitor execution history - Regularly check job runs for failures (async mode)
  5. Use timezone awareness - Always specify the correct timezone for business logic
  6. Validate JSON payloads - Ensure Job Arguments are valid JSON before saving
  7. Start with disabled schedules - Create new schedules in disabled state, test manually, then enable
  8. Document your schedules - Use the Description field to explain the purpose and impact

Troubleshooting​

Schedule Not Running​

  • Check if the schedule is Enabled
  • Verify the Next Run time is in the future
  • Ensure the scheduler process is running (yarn saasframe scheduler start)
  • For async mode, verify workers are running and Redis is accessible

Invalid Cron Expression​

  • Use a cron validator tool to test your expression
  • Remember: 5-field format (minute, hour, day, month, weekday)
  • Common mistake: Using 6-field format (with seconds) - not supported

Command Not Found​

  • Ensure the command is registered in the command registry
  • Check if the command exists in your modules
  • Verify the command ID matches exactly

Queue Job Not Processing​

  • Verify the queue name is correct
  • Ensure workers are listening to the target queue
  • Check worker logs for errors
  • Verify the JSON payload is valid

Technical Details​

Database Table​

Schedules are stored in the scheduled_jobs table with:

  • UUID primary key
  • Multi-tenant fields (tenant_id, organization_id)
  • Schedule configuration (type, value, timezone)
  • Target configuration (type, queue/command, payload)
  • Execution tracking (last_run_at, next_run_at)
  • Source tracking (user vs module created)

Events​

The scheduler emits events for monitoring:

  • scheduler.job.started - Job execution started
  • scheduler.job.completed - Job completed successfully
  • scheduler.job.failed - Job execution failed
  • scheduler.job.skipped - Job was skipped (disabled or feature flag)

Feature Flags​

Schedules can optionally require a feature flag:

  • Set require_feature field to enforce access control
  • Jobs are skipped if the user/tenant lacks the feature
  • Useful for premium features or beta functionality
