Payment Transactions

The Payment Transactions screen gives you a unified view of every transaction processed through the payment hub — regardless of provider. Navigate to External Systems → Payment Transactions.

Payment Transactions

Transaction list​

The top section shows all transactions in a searchable, filterable data table:

ColumnDescription
Payment IDThe internal payment reference (UUID). The smaller ID below is the transaction ID.
ProviderWhich gateway processed the transaction (e.g., Stripe, Mock).
StatusCurrent hub status: pending, authorized, captured, refunded, partially_refunded, cancelled, failed, expired.
AmountThe transaction amount in the original currency.
Session IDThe provider-side session identifier (e.g., Stripe Payment Intent ID pi_...).
Updated atWhen the transaction was last modified.

Use Filters and Perspectives to narrow results by status, provider, date range, or amount. The search box supports payment ID, transaction ID, and session ID lookups.

Transaction details​

Click any row to expand the detail panel below the table. The detail view includes:

Status cards​

  • Status — the Open Saasframe hub status (e.g., Refunded).
  • Gateway Status — the raw status from the provider (e.g., authorized from Stripe before capture).
  • Amount — the original transaction amount and currency.
  • Provider — which gateway adapter handled the transaction.

Identifiers​

  • Transaction ID — the hub-level unique identifier. Use this for all API operations (capture, refund, cancel, status).
  • Payment ID — the internal payment record reference.
  • Session ID — the provider session (e.g., Stripe Payment Intent ID).
  • Gateway Payment ID — provider-specific payment reference (if different from session).
  • Gateway Refund ID — populated after a refund (e.g., Stripe refund ID re_...).
  • Redirect URL — the hosted checkout URL, if the provider used a redirect flow.

Timestamps​

  • Created At / Updated At — when the transaction was first created and last modified.
  • Last Webhook — when the most recent webhook event was received for this transaction.
  • Last Poll — when the status was last refreshed via polling.

Refresh status​

Click Refresh status to query the payment provider for the latest state and update the local record. This is useful when webhooks are delayed or you want to force a sync.

Gateway metadata​

The Gateway metadata panel shows the raw JSON returned by the provider. For Stripe this includes the Payment Intent ID, charge ID, publishable key, and any capture or refund results. Click Copy to grab the full payload.

Webhook activity​

The Webhook activity section lists every inbound webhook event received for this transaction, with timestamps and event types. This helps you verify that Stripe (or another provider) is delivering events correctly.

Gateway logs​

Below webhook activity, Gateway logs show the low-level request/response log for API calls made to the provider during this transaction's lifecycle.

Tips​

  • Use the Status filter to quickly find transactions needing attention (e.g., authorized payments awaiting capture).
  • Cross-reference the Session ID with your Stripe Dashboard to match transactions between systems.
  • If a transaction shows an unexpected status, check Webhook activity first — missing events usually indicate a webhook configuration issue.
  • For programmatic access to transaction data, see the Payment Gateways REST API.
