AI Framework Overview

The AI Framework is a typed, module-owned runtime for building focused AI agents that can read and — with explicit user approval — mutate tenant data. It ships as part of @saasframe/ai-assistant alongside the existing OpenCode Code Mode chat surface.

Cmd/Ctrl+L opens the global AI assistant picker listing every agent the operator can launch

Two complementary surfaces

This framework does not replace the OpenCode-backed Command Palette (Cmd+K). Both stacks run side-by-side:

OpenCode Code Mode keeps powering the general-purpose Cmd+K chat with its two meta-tools (search + execute) against the OpenAPI spec.
The AI framework powers focused, typed agents embedded in admin pages via <AiChat>, structured-output callers via runAiAgentObject, and the D18 merchandising demo on /backend/catalog/catalog/products.

What you get

AiAgentDefinition — declarative agent contracts in <module>/ai-agents.ts with requiredFeatures, allowedTools, acceptedMediaTypes, readOnly, and mutationPolicy.
defineAiTool — typed tool definitions registered per module with isMutation, requiredFeatures, and Zod input schemas.
Tool packs — shared search.*, attachments.*, meta.* packs plus module-local packs (customers, catalog).
Chat and object execution modes — stream-first chat via runAiAgentText, structured outputs via runAiAgentObject.
Mutation approval gate — the ai_pending_actions table, three typed events (ai.action.confirmed|cancelled|expired), approval cards, and a TTL cleanup worker.
First-class agentic loop — declarative loop block (stopWhen, prepareStep, repairToolCall, budget), per-call overrides resolved through the same precedence chain as provider/model, operator budgets + kill switch at /backend/config/ai-assistant/agents, an SSE-driven LoopTrace rendered by <AiChat> and the playground, and an opt-in executionEngine: 'tool-loop-agent' backed by Vercel's Experimental_Agent. See agents → Agentic loop controls.
Prompt, mutation-policy, and loop-budget overrides — tenant-scoped additive prompt sections, non-escalating policy downgrades, and loop kill switch + budget caps at /backend/config/ai-assistant/agents.

Architecture flow

<AiChat agent="module.agent_id">
        │
        ▼
POST /api/ai_assistant/ai/chat?agent=<module>.<agent>
        │
        ├── checkAgentPolicy() — features, tool whitelist, mutationPolicy, media
        ├── createModelFactory().resolveModel() — LLM resolution
        ├── resolveAiAgentTools() — expose whitelisted tools to the model
        │
        ▼
runAiAgentText() / runAiAgentObject()
        │
        ├── Mutation tool call → prepareMutation() → ai_pending_actions row
        │   └── UI renders mutation-preview-card / field-diff-card
        │
        ▼
POST /api/ai/actions/:id/confirm   (user approves)
        │
        ├── runPendingActionRechecks() — stale-version guard
        ├── executePendingActionConfirm() — tool handler runs inside DB txn
        └── emit ai.action.confirmed → DOM event bridge → DataTable refresh

Agent contract at a glance

import type { AiAgentDefinition } from '@saasframe/ai-assistant'

export const agent: AiAgentDefinition = {
  id: 'customers.account_assistant',
  moduleId: 'customers',
  label: 'Account Assistant',
  description: 'Read-only CRM explorer for people, companies, deals.',
  systemPrompt: '...',
  allowedTools: ['search.entities', 'customers.get_person', /* ... */],
  readOnly: true,
  mutationPolicy: 'read-only',
  requiredFeatures: ['customers.view'],
  acceptedMediaTypes: ['image', 'pdf'],
}

See AI Agents for the full declaration guide and the end-to-end example.

Environment variables

Variable	Default	Purpose
`ANTHROPIC_API_KEY` / `OPENAI_API_KEY` / `GOOGLE_GENERATIVE_AI_API_KEY` / `OPENROUTER_API_KEY`	—	Standard provider keys; at least one MUST be set. The runtime picks the first configured provider via `llmProviderRegistry.resolveFirstConfigured()`. Other OpenAI-compatible providers use their matching `*_API_KEY` variables from `.env.example`.
`AI_PENDING_ACTION_TTL_SECONDS`	`900` (15 min)	Expiry window for pending mutation approvals. The cleanup worker flips stale rows to `expired`.
`SF_AI_<MODULE>_MODEL`	unset	Per-module model override. Uppercased from the `moduleId`. Examples: `SF_AI_INBOX_OPS_MODEL=claude-haiku-4-5`, `SF_AI_CATALOG_MODEL=gpt-4o-mini`. The legacy `<MODULE>_AI_MODEL` form (`INBOX_OPS_AI_MODEL`, `CATALOG_AI_MODEL`) is read as a backward-compatibility fallback.
`SF_AI_<MODULE>_PROVIDER`	unset	Per-module provider override (Phase 1). Uppercased from the `moduleId`. Examples: `SF_AI_CATALOG_PROVIDER=openai`, `SF_AI_INBOX_OPS_PROVIDER=anthropic`. The legacy `<MODULE>_AI_PROVIDER` form is read as a backward-compatibility fallback. A provider-only preference can fall through when unconfigured; a paired provider/model override fails instead of sending that model to another provider.
`SF_AI_PROVIDER`	`openai` (when an `OPENAI_API_KEY` is set)	Process-wide default provider id. Built-in ids: `openai`, `anthropic`, `google`, `deepinfra`, `groq`, `together`, `fireworks`, `azure`, `litellm`, `ollama`, `openrouter`, `requesty`, `lm-studio`. A provider-only preference can fall through when unconfigured; when paired with `SF_AI_MODEL`, the provider must be configured. Legacy `OPENCODE_PROVIDER` is read as a backward-compatibility fallback.
`SF_AI_MODEL`	`gpt-5-mini` (under the default `openai` provider)	Process-wide default model id. Plain ids resolve under the chosen provider; slash-qualified ids (`openai/gpt-5-mini`) consume the provider axis at the same step. DeepInfra-style ids that already contain slashes (`meta-llama/Llama-3.3-70B-Instruct-Turbo`) stay intact via the registry-membership guard. Legacy `OPENCODE_MODEL` is read as a backward-compatibility fallback.
`SF_AI_AVAILABLE_PROVIDERS`	unset	Operator-defined ALLOWLIST of provider ids that the runtime accepts (comma-separated, whitespace-tolerant, case-insensitive). Unset / empty → no restriction. When set, the settings UI is clipped to this subset, the chat-UI `<ModelPicker>` only offers these values, the dispatcher rejects out-of-allowlist `?provider=` query params with `provider_not_allowlisted` 400, and the model-factory swaps to a safe pair (with `console.warn` + an `allowlistFallback` field on the resolution) whenever a higher-priority source resolves to a blocked provider.
`SF_AI_AVAILABLE_MODELS_<PROVIDER>`	unset	Per-provider ALLOWLIST of model ids (comma-separated, case-sensitive). `<PROVIDER>` is uppercased from the registry id (e.g. `SF_AI_AVAILABLE_MODELS_OPENAI=gpt-5-mini,gpt-5`). Unset / empty → no model restriction for that provider. Honored at the same gates as `SF_AI_AVAILABLE_PROVIDERS`; the dispatcher 400 code is `model_not_allowlisted`.
`SF_AI_AGENT_<AGENT_ID>_AVAILABLE_PROVIDERS`	unset	Per-agent chat override ALLOWLIST. `<AGENT_ID>` is the full agent id uppercased with non-alphanumerics replaced by `_` (for example `catalog.catalog_assistant` → `SF_AI_AGENT_CATALOG_CATALOG_ASSISTANT_AVAILABLE_PROVIDERS`). This only limits what users can pick in the chat footer and what `?provider=&model=` request overrides may use; it does not change the agent's default model.
`SF_AI_AGENT_<AGENT_ID>_AVAILABLE_MODELS_<PROVIDER>`	unset	Per-agent, per-provider chat override model ALLOWLIST. Example: `SF_AI_AGENT_CATALOG_CATALOG_ASSISTANT_AVAILABLE_MODELS_OPENAI=gpt-5-mini,gpt-4o`. The value is intersected with `SF_AI_AVAILABLE_*`, the tenant allowlist, and the per-agent settings-page picker allowlist.

SF_AI_PROVIDER / SF_AI_MODEL are the canonical names; the legacy OPENCODE_PROVIDER / OPENCODE_MODEL envs stay bound to the OpenCode Code Mode stack and are also honored as backward-compatibility fallbacks for the unified AI runtime.

SF_AI_AVAILABLE_PROVIDERS / SF_AI_AVAILABLE_MODELS_<PROVIDER> are the OUTER runtime constraint — they sit on top of every default or override source. The runtime then intersects them with the per-tenant allowlist persisted in ai_tenant_model_allowlists (edited from /backend/config/ai-assistant/allowlist) so admins can narrow further without touching env. Chat-footer user overrides are narrowed one step more by SF_AI_AGENT_<AGENT_ID>_AVAILABLE_* and the selected agent's Chat override choices panel on /backend/config/ai-assistant/agents.

The default-model chain is env → tenant allowlist → tenant runtime override → per-request override. When a higher-priority source resolves to a (provider, model) outside the effective runtime allowlist (env ∩ tenant), the factory swaps to a safe pair using this order: (1) the agent's defaultProvider + defaultModel if both are allowed and configured; (2) the first allowed provider that is also configured in the registry, then that provider's defaultModel if allowed, else the first model from the effective list for that provider. The resolution returns source: 'allowlist_fallback' and an allowlistFallback field describing the rejected pair. The settings PUT endpoint rejects out-of-effective values up-front (provider_not_allowlisted / model_not_allowlisted 400). Tenant snapshots may NEVER widen env — PUT /api/ai_assistant/settings/allowlist rejects out-of-env entries with provider_not_in_env_allowlist / model_not_in_env_allowlist 400.

For OpenRouter, use SF_AI_PROVIDER=openrouter with OPENROUTER_API_KEY and an OpenRouter model id such as meta-llama/llama-3.3-70b-instruct or a vendor-prefixed id like anthropic/claude-sonnet-4.5 — the full id is passed through to OpenRouter. OPENROUTER_BASE_URL is available for proxy/custom gateway deployments.

For local LLMs, use SF_AI_PROVIDER=lm-studio with LM_STUDIO_BASE_URL=http://localhost:1234/v1, or SF_AI_PROVIDER=ollama with OLLAMA_BASE_URL=http://localhost:11434/v1. Set SF_AI_MODEL to the exact local model id exposed by the server, for example a loaded Llama instruct model in LM Studio or llama3.3 in Ollama.

Model resolution order

The shared createModelFactory(container) picks one model per agent run. Highest precedence first:

Step	Source	How to set
1	Runtime override — model sent by the browser `<ModelPicker>` via `?provider=&model=` query params	User selects in the chat composer; stored in `localStorage` per agent, forwarded by `<AiChat>`
2	Tenant settings override — `(provider, model)` row in `ai_agent_runtime_overrides` scoped to the tenant	Admin saves at `/backend/config/ai-assistant/settings` → Global Override form
3	Per-agent tenant settings override — `(provider, model)` row in `ai_agent_runtime_overrides` scoped to a specific `agentId`	Admin saves at `/backend/config/ai-assistant/agents` → Provider and model
4	`SF_AI_<MODULE>_MODEL` env var (legacy `<MODULE>_AI_MODEL` fallback)	`SF_AI_CATALOG_MODEL=gpt-4o` in `.env`; uppercased from `moduleId`
5	`AiAgentDefinition.defaultModel`	Optional agent-level pin in `ai-agents.ts`; omit for generic shipped agents so env controls the model
6	`SF_AI_MODEL` env var (legacy `OPENCODE_MODEL` fallback)	Process-wide fallback, plain or slash-qualified (`openai/gpt-5-mini`)
7	Provider default	Hard-coded per provider (e.g. `claude-haiku-4-5-20251001` for Anthropic)

Steps 1–3 are only active when allowRuntimeModelOverride is true for the agent (default: true). The runtime skips tenant/runtime overrides when the field is false, so agents that need strict model pinning can opt out.

The provider axis is resolved through llmProviderRegistry.resolveFirstConfigured. Phase 1 generalizes the seed walk so every model-axis source contributes a slash hint and plain-provider sources sit between them (highest priority first):

Provider from runtime/tenant override (steps 1–3 above), including any slash-prefix on the override's model id.
Slash-prefix from callerOverride (Phase 1).
providerOverride — request-time override on runAiAgentText / runAiAgentObject (Phase 1).
Slash-prefix from SF_AI_<MODULE>_MODEL (legacy <MODULE>_AI_MODEL BC fallback).
SF_AI_<MODULE>_PROVIDER env (legacy <MODULE>_AI_PROVIDER BC fallback).
Slash-prefix from agentDefaultModel.
agentDefaultProvider — AiAgentDefinition.defaultProvider.
Slash-prefix from SF_AI_MODEL (legacy OPENCODE_MODEL BC fallback).
SF_AI_PROVIDER env (legacy OPENCODE_PROVIDER BC fallback).

Provider-only preferences can fall through when the named provider is registered but unconfigured. Provider/model pairs are atomic: if the selected model source is slash-qualified (anthropic/claude-sonnet-4-20250514) or paired with the same-source provider field/env var (SF_AI_PROVIDER=anthropic + SF_AI_MODEL=claude-sonnet-4-20250514), that provider must be configured. The factory fails closed instead of sending the model id to another provider.

Example: full resolution trace

Agent: catalog.merchandising_assistant  (moduleId: catalog)
Env:   ANTHROPIC_API_KEY set, SF_AI_PROVIDER=anthropic

Browser sends ?provider=openai&model=gpt-4o  ← Step 1 wins → uses openai/gpt-4o
Browser sends nothing, tenant has override (openai, gpt-5-mini) ← Step 2 wins
Tenant has per-agent override for catalog.merch (google, gemini-3-pro) ← Step 3 wins
No runtime/tenant override, SF_AI_CATALOG_MODEL=gpt-4o-mini ← Step 4 wins
No env, agent intentionally pins defaultModel/defaultProvider ← Step 5 wins
No agent default, SF_AI_MODEL=openai/gpt-5-mini ← Step 6 wins
No SF_AI_MODEL, Anthropic key present ← Step 7: anthropic/claude-haiku-4-5-20251001

Do not re-introduce ad-hoc provider lookups

Route every model creation through createModelFactory(container).resolveModel({...}). Inline createAnthropic / createOpenAI / createGoogleGenerativeAI calls in new modules will be rejected in review.

Migration and backward compatibility

The release is additive — no existing event ids, API routes, widget spot ids, DI keys, ACL feature ids, notification type ids, CLI commands, or generated file contracts were renamed or removed.

Migration20260419134235_ai_assistant adds ai_pending_actions, ai_agent_prompt_overrides, and ai_agent_mutation_policy_overrides. Apply via yarn db:migrate.
After migrate, refresh the structural cache so the cleanup worker registers on existing tenants:
```
yarn saasframe configs cache structural --all-tenants
```
OpenCode's /api/chat, /api/tools, and /api/tools/execute routes are untouched. The new dispatcher lives at /api/ai_assistant/ai/chat and the pending-action routes under /api/ai/actions/:id/*.

Where to go next

Architecture — system map, request flow, persistence, generators.
Developer Guide — soup-to-nuts walkthrough for adding a new agent end-to-end.
AI Agents — ai-agents.ts, tool packs, chat vs object mode, escape hatches.
UI Parts — record cards + custom inline widgets the agent streams into the chat.
Attachments — file upload contract, base64 inline encoding, the input-index pairing.
Mutation Approvals — ai_pending_actions lifecycle, events, approval cards.
Global Launcher — topbar AI button + Cmd/Ctrl+L global shortcut.
Overrides — replace or disable agents and tools registered by other modules.
Agent Settings — prompt overrides and mutation-policy overrides at /backend/config/ai-assistant/agents.
Playground — interactive sandbox for running agents with structured inputs.
